If you own a Ford Mondeo Mk4 (2007-2014) and are planning to replace the battery, it’s worth considering the specifications appropriate for your engine version. The table presents the required battery capacity and starting current, as well as examples of suitable battery models.
For petrol engines such as the 1.6 Ti, 2.0, and 2.0 Flexifuel, it is recommended to choose a battery with a capacity of 60 to 62 Ah and a starting current of 540-600 A. Examples of compatible batteries include the Varta D59 and Bosch S40 04. Interestingly, the same batteries will fit both the 2.0 Flexifuel and LPG versions, which have identical requirements.
For larger engines like the 2.3 and 2.5, you should select a battery with a larger capacity – between 71 and 74 Ah and a starting current of 670-750 A. Suitable examples are the Exide EA722 and Exide EB712. These engines require more power, which translates into the need for more efficient batteries.
For Start-Stop technology engines like the 1.6 EcoBoost and 1.6 TDCi, EFB-type batteries are recommended, as they are specifically designed for frequent engine starts. A capacity of 75 Ah and a starting current of 730 A are required. Examples of suitable models are the Varta E46 and Halfords EFB 110.
Diesel engines such as the 1.8 TDCi, 2.0 TDCi, and 2.2 TDCi require batteries with similar parameters – 71-74 Ah and a starting current of 670-750 A. Suitable models include the Exide EA722, Bosch S50 07, and Lucas LS100, meaning the same batteries can be used across different engine versions.
Choosing the right battery is essential for your vehicle’s proper functioning. Regularly checking the battery’s charge status and replacing it every few years can help avoid unexpected issues, especially in winter when the battery is under more strain.
Ford Mondeo in version Mk4 was produced in the years 2007 – 2014. The following table presents information about batteries that match each of the engines available on the market.
Basic parameters of batteries suitable for Ford Mondeo (2007-2014):
| Layout | Terminal types | Base hold-down |
|---|---|---|
| 0 – positive on the right side | 1 | B13 |
Ford Mondeo Mk4 – petrol engines:
- 1.6 Ti
- 2.0
- 2.0 Flexifuel
- 2.0 LPG
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 04 | 60 Ah 540 A | 242x175x175 mm | More |
| Bosch S5 S50 04 | 61 Ah 600 A | 242x175x175 mm | More |
| Exide Excell EB602 | 60 Ah 540 A | 242x175x175 mm | More |
| Exide Premium EA612 | 61 Ah 600 A | 242x175x175 mm | More |
| Halfords Standard HCB 075 | 60 Ah 550 A | 242x175x175 mm | More |
| Lucas Premium LP075 | 60 Ah 540 A | 243x175x175 mm | More |
| Lucas Supreme LS075 | 62 Ah 600 A | 242x175x175 mm | More |
| Varta Blue Dynamic D59 | 60 Ah 540 A | 242x175x175 mm | More |
| Varta Silver Dynamic D21 | 61 Ah 600 A | 242x175x175 mm | More |
For the petrol engines of the Ford Mondeo Mk4 produced between 2007 and 2014—specifically the 1.6 Ti without Start-Stop, 2.0 without Start-Stop, 2.0 Flexifuel without Start-Stop, and 2.0 LPG without Start-Stop—a particular group of batteries is most suitable. These engines do not require the advanced battery technology used in Start-Stop systems, making standard lead-acid batteries an appropriate and reliable choice. The most compatible battery type for these engines features a standard fitment with a B13 base hold-down and conventional terminal layout, ensuring straightforward installation and secure mounting.
In terms of specifications, these engines are best served by batteries with a capacity ranging from 60 to 62 Ah and a cold cranking amperage (CCA) between 540 and 600 A. The batteries that fit these requirements typically measure around 242 mm in length, 175 mm in width, and 175 mm in height, with some slight variation depending on the specific brand and model. The terminal layout is standard European (layout 0), and the terminal type is the common round post (type 1), which matches the original battery configuration used by Ford for these Mondeo engines.
There are several reputable manufacturers offering suitable batteries for these Mondeo petrol engines. Bosch provides the S4 (S40 04) and S5 (S50 04) series, both widely recognized for their reliability and performance in everyday conditions. Varta’s Blue Dynamic (D59) and Silver Dynamic (D21) lines offer similar fitment and performance, as do Exide’s Premium (EA612) and Excell (EB602) models. Alternatives from Halfords (HCB 075) and Lucas (Supreme LS075 and Premium LP075) also meet the necessary technical and dimensional standards. All these options guarantee compatibility in terms of size, mounting, and electrical characteristics, ensuring dependable engine starts and system operation for the specified petrol engine variants of the Ford Mondeo Mk4.
Ford Mondeo Mk4 – petrol engines:
- 2.0 EcoBoost
- 2.0 SCTi
- 2.3
- 2.5
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 07 | 72 Ah 680 A | 278x175x175 mm | More |
| Bosch S5 S50 07 | 74 Ah 750 A | 278x175x175 mm | More |
| Exide Excell EB712 | 71 Ah 670 A | 278x175x175 mm | More |
| Exide Premium EA722 | 72 Ah 720 A | 278x175x175 mm | More |
| Lucas Premium LP100 | 72 Ah 680 A | 278x175x175 mm | More |
| Lucas Supreme LS100 | 74 Ah 750 A | 278x175x175 mm | More |
| Varta Blue Dynamic E43 | 72 Ah 680 A | 278x175x175 mm | More |
| Varta Silver Dynamic E38 | 74 Ah 750 A | 278x175x175 mm | More |
For the larger petrol engines in the Ford Mondeo Mk4 produced from 2007 to 2014—specifically the 2.0 EcoBoost without Start-Stop, 2.0 SCTi without Start-Stop, 2.3 without Start-Stop, and 2.5 without Start-Stop—a different group of batteries is recommended to meet their increased electrical demands. These engines benefit from batteries with a higher capacity and greater cold cranking performance compared to the smaller petrol units, ensuring reliable starting power and stable operation of all onboard systems. As with the previously described engines, these variants do not require Start-Stop compatible batteries, so high-quality standard lead-acid batteries remain the ideal choice.
The most suitable batteries for these engines feature a capacity in the range of 71 to 74 Ah and a cold cranking amperage (CCA) between 670 and 750 A. These batteries are slightly larger, with typical dimensions of 278 mm in length, 175 mm in width, and 175 mm in height, and maintain the standard European terminal arrangement (layout 0) with round post terminals (type 1). The B13 base hold-down ensures secure and straightforward installation within the engine bay, matching the original mounting configuration used by Ford for these higher-displacement petrol engines.
Leading manufacturers offer several reliable options that meet these requirements. Bosch supplies the S4 (S40 07) and S5 (S50 07) series, both recognized for their durability and consistent performance under demanding conditions. Varta’s Blue Dynamic (E43) and Silver Dynamic (E38) batteries deliver excellent starting power and longevity, while Exide’s Premium (EA722) and Excell (EB712) series provide similar levels of fitment and reliability. Additionally, Lucas offers the Supreme (LS100) and Premium (LP100) models, which also fulfill the necessary technical specifications. All these batteries guarantee full compatibility with the 2.0 EcoBoost, 2.0 SCTi, 2.3, and 2.5 petrol engines of the Ford Mondeo Mk4, ensuring optimal performance and reliability for everyday driving.
Ford Mondeo Mk4 – petrol engines:
- 1.6 EcoBoost – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E10 | 75 Ah 730 A | 315x175x175 mm | More |
| Exide EFB EL752 | 75 Ah 730 A | 315x175x175 mm | More |
| Halfords Advanced EFB 110 | 75 Ah 730 A | 317x175x175 mm | More |
| Lucas Fusion EFB LE110 | 75 Ah 730 A | 315x175x175 mm | More |
| Varta Blue Dynamic EFB E46 | 75 Ah 730 A | 315x175x175 mm | More |
For the 1.6 EcoBoost Start-Stop petrol engine in the Ford Mondeo Mk4, produced between 2007 and 2014, a different battery technology is required compared to the non-Start-Stop petrol variants. Because this engine is equipped with Start-Stop functionality, it demands enhanced durability and greater resistance to frequent charge-discharge cycles. As a result, only batteries based on EFB (Enhanced Flooded Battery) technology are recommended for this engine. EFB batteries are specifically engineered to support Start-Stop systems, offering improved charge acceptance and extended service life under the higher cycling conditions characteristic of this feature.
The most suitable EFB batteries for the 1.6 EcoBoost Start-Stop engine share a set of common specifications. These include a nominal capacity of 75 Ah and a cold cranking amperage (CCA) of 730 A, ensuring reliable engine starts and adequate power supply to electrical systems during repeated Start-Stop cycles. In terms of physical dimensions, these batteries typically measure around 315 to 317 mm in length, 175 mm in width, and 175 mm in height. They employ the standard European terminal layout (layout 0) with round post terminals (type 1) and utilize a B13 base hold-down, matching the original mounting specifications provided by Ford.
Major manufacturers offer EFB batteries suitable for this application, including the Bosch S4 EFB (S4 E10), Varta Blue Dynamic EFB (E46), Exide EFB (EL752), Lucas Fusion EFB (LE110), and Halfords Advanced EFB 110. Each of these batteries is fully compatible with the physical and electrical requirements of the 1.6 EcoBoost Start-Stop engine. Using an EFB battery from one of these reputable brands will ensure optimal Start-Stop system performance, reliable starting power, and the longevity necessary for everyday driving with this modern engine technology.
Ford Mondeo Mk4 – diesel engines:
- 1.8 TDCi
- 2.0 TDCi
- 2.2 TDCi
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 07 | 72 Ah 680 A | 278x175x175 mm | More |
| Bosch S5 S50 07 | 74 Ah 750 A | 278x175x175 mm | More |
| Exide Excell EB712 | 71 Ah 670 A | 278x175x175 mm | More |
| Exide Premium EA722 | 72 Ah 720 A | 278x175x175 mm | More |
| Lucas Premium LP100 | 72 Ah 680 A | 278x175x175 mm | More |
| Lucas Supreme LS100 | 74 Ah 750 A | 278x175x175 mm | More |
| Varta Blue Dynamic E43 | 72 Ah 680 A | 278x175x175 mm | More |
| Varta Silver Dynamic E38 | 74 Ah 750 A | 278x175x175 mm | More |
For the diesel variants of the Ford Mondeo Mk4 produced between 2007 and 2014—specifically the 1.8 TDCi, 2.0 TDCi, and 2.2 TDCi engines without Start-Stop systems—a distinct group of batteries is most appropriate to meet their higher demands for starting power and overall reliability. While these engines do not require the advanced features of AGM or EFB batteries used in Start-Stop applications, they do benefit from batteries with a larger capacity and greater cold cranking amperage, given the increased compression ratios typical of diesel engines. Standard lead-acid batteries from recognized manufacturers remain the best choice, provided they offer robust starting performance and fitment consistency.
The ideal batteries for these diesel engines feature a capacity in the range of 71 to 74 Ah, paired with a cold cranking amperage (CCA) between 670 and 750 A. Physically, these batteries are designed to fit perfectly in the Mondeo’s engine bay, with dimensions of 278 mm in length, 175 mm in width, and 175 mm in height. They utilize the standard European terminal layout (layout 0), round post terminals (type 1), and a B13 base hold-down for secure and straightforward installation. This configuration matches the original equipment specifications provided by Ford for these diesel models, ensuring both compatibility and ease of replacement.
Several reputable brands offer batteries that meet or exceed these requirements. Bosch’s S4 (S40 07) and S5 (S50 07) series deliver dependable starting power and long service life, while Varta’s Blue Dynamic (E43) and Silver Dynamic (E38) lines are known for their consistent performance and reliability. Exide’s Premium (EA722) and Excell (EB712) models also provide strong cold cranking capabilities and proven durability under the demands of diesel operation. Additionally, Lucas offers the Supreme (LS100) and Premium (LP100) batteries, both of which fully comply with the necessary technical and physical standards. Each of these options represents a reliable solution for the 1.8 TDCi, 2.0 TDCi, and 2.2 TDCi engines, ensuring dependable cold starts and stable power delivery throughout all seasons and driving conditions.
Ford Mondeo Mk4 – diesel engines:
- 1.6 TDCi – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E10 | 75 Ah 730 A | 315x175x175 mm | More |
| Exide EFB EL752 | 75 Ah 730 A | 315x175x175 mm | More |
| Halfords Advanced EFB 110 | 75 Ah 730 A | 317x175x175 mm | More |
| Lucas Fusion EFB LE110 | 75 Ah 730 A | 315x175x175 mm | More |
| Varta Blue Dynamic EFB E46 | 75 Ah 730 A | 315x175x175 mm | More |
For the 1.6 TDCi Start-Stop diesel engine in the Ford Mondeo Mk4, produced between 2007 and 2014, a specialized group of batteries is required to support the unique demands of the Start-Stop system. Unlike the non-Start-Stop diesel variants, this engine relies on Enhanced Flooded Battery (EFB) technology, which is specifically designed to handle the frequent charge and discharge cycles imposed by Start-Stop operation. EFB batteries deliver improved charge acceptance, increased resistance to deep discharges, and a longer service life, making them essential for maintaining reliable performance in vehicles equipped with Start-Stop functionality.
The most compatible batteries for the 1.6 TDCi Start-Stop share several key specifications. Each offers a nominal capacity of 75 Ah and a cold cranking amperage (CCA) of 730 A, ensuring robust starting power and consistent electrical supply during repeated engine restarts. The physical dimensions of these batteries—typically 315 to 317 mm in length, 175 mm in width, and 175 mm in height—are engineered to fit precisely within the Mondeo’s battery compartment. They utilize the standard European terminal layout (layout 0) with round post terminals (type 1) and are secured with a B13 base hold-down, matching the original factory installation.
Reputable manufacturers provide a range of EFB batteries meeting these requirements, including the Bosch S4 EFB (S4 E10), Varta Blue Dynamic EFB (E46), Exide EFB (EL752), Lucas Fusion EFB (LE110), and Halfords Advanced EFB 110. Each of these batteries is fully compatible with the electrical and physical specifications for the 1.6 TDCi Start-Stop engine. Selecting an EFB battery from one of these trusted brands ensures the Start-Stop system operates efficiently, with reliable starting performance and the durability needed for daily use in varying driving conditions. This focus on EFB technology for the 1.6 TDCi Start-Stop further distinguishes it from both petrol Start-Stop and non-Start-Stop diesel variants in the Mondeo Mk4 range.
If you’re still unsure which battery fits your Ford Mondeo , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
