The Ford Mondeo Mk5 (2014-2022) is a modern vehicle with a variety of engine options, all of which utilize a Start-Stop system to improve fuel efficiency and reduce emissions. This system requires a high-performance battery, particularly one with EFB (Enhanced Flooded Battery) technology, which offers improved durability and resistance to frequent charge and discharge cycles. Selecting the correct battery for your Mondeo depends on the engine type, required capacity, and specific installation requirements.
For petrol engines, the 1.0 EcoBoost (92 kW) requires a 65Ah EFB battery with 650A cold cranking amps (CCA). Due to the vehicle’s design, it’s essential to choose a battery with a reduced height of 175mm. Some example models that fit these requirements include the Bosch S4 E07, Exide EL652, Halfords EFB 100, Lucas LE100, and Varta D54.
The more powerful 1.5 EcoBoost (121 kW) engine requires a slightly larger 70-75Ah EFB battery with a minimum of 650A and a maximum of 760A CCA. This engine provides more power and is often found in Mondeo models with additional electrical consumers, meaning a strong battery is necessary. Some suitable examples include the Bosch S4 E08, Exide EL700, Halfords EFB 096, Lucas LE096, Varta E45, and Varta N70.
For the 1.5 EcoBoost (118 kW), 2.0 EcoBoost (149 kW), and 2.0 EcoBoost (176 kW) engines, Ford specifies a 75Ah EFB battery with 730A CCA. As with the 1.0 EcoBoost, these engines require a battery with a height of 175mm, which is shorter than standard European sizes. Some compatible models for these engines include the Bosch S4 E10, Exide EL752, Halfords EFB 110, Lucas LE110, and Varta E46.
For diesel engines, battery requirements vary slightly but maintain the EFB technology. The 2.0 EcoBlue (88 kW, 110 kW, and 140 kW) engines use a 70-75Ah battery with 650-760A CCA. As these engines provide robust performance, particularly on long drives, they require a stable and reliable battery. Some example models for these versions include Bosch S4 E08, Exide EL700, Halfords EFB 096, Lucas LE096, Varta E45, and Varta N70.
For higher-output diesel engines, including the 1.5 TDCi (88 kW), 1.6 TDCi (85 kW), 2.0 TDCi (110 kW, 132 kW), and 2.0 TDCi BiTurbo (154 kW), a 75Ah EFB battery with 730A CCA is required. As with several petrol models, these diesel versions also require a reduced battery height of 175mm for proper installation. This limitation makes it crucial to check battery specifications carefully before purchasing. Some suitable battery models include the Bosch S4 E10, Exide EL752, Halfords EFB 110, Lucas LE110, and Varta E46.
One of the most critical aspects when choosing a battery for the Ford Mondeo Mk5 is ensuring that the dimensions are correct, particularly in models requiring 175mm height. Many standard European batteries have a height of 190mm, which would not fit correctly in certain Mondeo versions. Therefore, it is always recommended to double-check the current battery’s size before purchasing a replacement.
EFB batteries are designed to withstand the frequent charge and discharge cycles caused by the Start-Stop system, making them significantly more durable than traditional lead-acid batteries. However, if the vehicle’s electrical demands are higher due to extensive use of additional electronics (heated seats, advanced infotainment, multiple sensors), upgrading to an AGM (Absorbent Glass Mat) battery may be a long-term solution, though the Mondeo Mk5 was primarily designed for EFB technology.
Selecting the right battery for the Ford Mondeo Mk5 (2014-2022) depends on the engine type and specific space limitations. EFB batteries are the best choice for maintaining the efficiency of the Start-Stop system, providing durability, and ensuring reliability during cold starts. Before purchasing a new battery, always confirm the dimensions, especially the height, to ensure compatibility. Investing in a high-quality battery will help maintain the vehicle’s electrical system and prevent unexpected failures.
Ford Mondeo in version Mk5 was produced in the years 2014 – 2022. Below we present the specifications of batteries suitable for specific engines.
Basic parameters of batteries suitable for Ford Mondeo (2014-2022):
| Layout | Terminal types | Base hold-down |
|---|---|---|
| 0 – positive on the right side | 1 | B13 |
Ford Mondeo Mk5 – petrol engines:
- 1.0 EcoBoost (92 kW) – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E07 | 65 Ah 650 A | 278x175x175 mm | More |
| Exide EFB EL652 | 65 Ah 650 A | 278x175x175 mm | More |
| Halfords Advanced EFB 100 | 65 Ah 650 A | 277x175x175 mm | More |
| Lucas Fusion EFB LE100 | 65 Ah 650 A | 278x175x175 mm | More |
| Varta Blue Dynamic EFB D54 | 65 Ah 650 A | 278x175x175 mm | More |
Ford Mondeo Mk5 – petrol engines:
- 1.5 EcoBoost (121 kW) – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E08 | 70 Ah 650 A | 278x175x190 mm | More |
| Exide EFB EL700 | 70 Ah 720 A | 278x175x190 mm | More |
| Halfords Advanced EFB 096 | 75 Ah 700 A | 278x175x190 mm | More |
| Lucas Fusion EFB LE096 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB E45 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB N70 | 70 Ah 760 A | 278x175x190 mm | More |
Ford Mondeo Mk5 – petrol engines:
- 1.5 EcoBoost (118 kW) – with Start-Stop
- 2.0 EcoBoost (149 kW) – with Start-Stop
- 2.0 EcoBoost (176 kW) – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E10 | 75 Ah 730 A | 315x175x175 mm | More |
| Exide EFB EL752 | 75 Ah 730 A | 315x175x175 mm | More |
| Halfords Advanced EFB 110 | 75 Ah 730 A | 317x175x175 mm | More |
| Lucas Fusion EFB LE110 | 75 Ah 730 A | 315x175x175 mm | More |
| Varta Blue Dynamic EFB E46 | 75 Ah 730 A | 315x175x175 mm | More |
Ford Mondeo Mk5 – diesel engines:
- 2.0 EcoBlue (110 kW) – with Start-Stop
- 2.0 EcoBlue (140 kW) – with Start-Stop
- 2.0 EcoBlue (88 kW) – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E08 | 70 Ah 650 A | 278x175x190 mm | More |
| Exide EFB EL700 | 70 Ah 720 A | 278x175x190 mm | More |
| Halfords Advanced EFB 096 | 75 Ah 700 A | 278x175x190 mm | More |
| Lucas Fusion EFB LE096 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB E45 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB N70 | 70 Ah 760 A | 278x175x190 mm | More |
Ford Mondeo Mk5 – diesel engines:
- 1.5 TDCi (88 kW) – with Start-Stop
- 1.6 TDCi (85 kW) – with Start-Stop
- 2.0 TDCi (110 kW) – with Start-Stop
- 2.0 TDCi (132 kW) – with Start-Stop
- 2.0 TDCi BiTurbo (154 kW) – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E10 | 75 Ah 730 A | 315x175x175 mm | More |
| Exide EFB EL752 | 75 Ah 730 A | 315x175x175 mm | More |
| Halfords Advanced EFB 110 | 75 Ah 730 A | 317x175x175 mm | More |
| Lucas Fusion EFB LE110 | 75 Ah 730 A | 315x175x175 mm | More |
| Varta Blue Dynamic EFB E46 | 75 Ah 730 A | 315x175x175 mm | More |
If you’re still unsure which battery fits your Ford Mondeo , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
