Opel Astra J (Astra 4) (2009-2015) - batteries

Opel Astra in version J (Astra 4) was produced in the years 2009 – 2015. We invite you to a list of batteries matching individual engine versions.

Basic parameters of batteries suitable for Opel Astra (2009-2015):

Layout	Terminal types	Base hold-down
0 – positive on the right side	1	B13

Opel Astra J (Astra 4) – petrol engines:
1.4
1.4 LPG
1.4 Turbo
1.6
1.6 LPG
1.6 SIDI
1.6 Turbo (180 KM)

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S4 S40 04	60 Ah 540 A	242x175x175 mm	More
Bosch S5 S50 04	61 Ah 600 A	242x175x175 mm	More
Exide Excell EB602	60 Ah 540 A	242x175x175 mm	More
Exide Premium EA612	61 Ah 600 A	242x175x175 mm	More
Halfords Standard HCB 075	60 Ah 550 A	242x175x175 mm	More
Lucas Premium LP075	60 Ah 540 A	243x175x175 mm	More
Lucas Supreme LS075	62 Ah 600 A	242x175x175 mm	More
Varta Blue Dynamic D59	60 Ah 540 A	242x175x175 mm	More
Varta Silver Dynamic D21	61 Ah 600 A	242x175x175 mm	More

For the 1.4, 1.4 LPG, 1.4 Turbo petrol engines and others from the above list, we select batteries measuring 242x175x175 mm or 243x175x175 mm with a capacity exceeding 57 Ah. The weakest of these is the battery Bosch S4 S40 04 which capacity is 60 Ah and Cold Cranking Amps is 540 A. The most powerful battery is Lucas Supreme LS075 of a capacity 62Ah and Cold Cranking Amps: 600 A. All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – petrol engines:
1.4 Turbo – with Start-Stop
1.6 SIDI – with Start-Stop

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S5 AGM S5A 08	70 Ah 760 A	278x175x190 mm	More
Exide AGM EK700	70 Ah 760 A	278x175x190 mm	More
Exide AGM EK720	72 Ah 760 A	278x175x190 mm	More
Halfords Standard AGM 096	70 Ah 720 A	278x175x190 mm	More
Halfords Advanced AGM 096	70 Ah 760 A	278x175x190 mm	More
Lucas Fusion AGM LF096	70 Ah 760 A	278x175x190 mm	More
Varta Silver Dynamic AGM E39	70 Ah 760 A	278x175x190 mm	More

1.4 Turbo or 1.6 SIDI engines in the Opel Astra J (Astra 4) with Start-Stop system require the use of AGM technology batteries. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 720 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.

Opel Astra J (Astra 4) – diesel engines:
1.3 CDTI
1.7 CDTI

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S4 S40 04	60 Ah 540 A	242x175x175 mm	More
Bosch S5 S50 04	61 Ah 600 A	242x175x175 mm	More
Exide Excell EB602	60 Ah 540 A	242x175x175 mm	More
Exide Premium EA612	61 Ah 600 A	242x175x175 mm	More
Halfords Standard HCB 075	60 Ah 550 A	242x175x175 mm	More
Lucas Premium LP075	60 Ah 540 A	243x175x175 mm	More
Lucas Supreme LS075	62 Ah 600 A	242x175x175 mm	More
Varta Blue Dynamic D59	60 Ah 540 A	242x175x175 mm	More
Varta Silver Dynamic D21	61 Ah 600 A	242x175x175 mm	More

For the Opel Astra J (Astra 4) with 1.3 CDTI or 1.7 CDTI diesel engines, we recommend batteries sized 242x175x175 mm or 243x175x175 mm, with a minimum capacity of 57 Ah. The most basic battery of this set is Bosch S4 S40 04 of a capacity 60Ah and 540A Cold Cranking Amps, the battery with the biggest capacity is Lucas Supreme LS075 of a capacity 62 Ah, having 600A Cold Cranking Amps. All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – diesel engines:
1.3 CDTI – with Start-Stop

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S4 EFB S4 E05	60 Ah 560 A	242x175x190 mm	More
Exide EFB EL600	60 Ah 640 A	242x175x190 mm	More
Halfords Advanced EFB 027	65 Ah 600 A	243x175x190 mm	More
Lucas Fusion EFB LE027	60 Ah 560 A	242x175x190 mm	More
Varta Blue Dynamic EFB N60	60 Ah 640 A	242x175x190 mm	More
Varta Blue Dynamic EFB D53	60 Ah 560 A	242x175x190 mm	More

Owning a Opel Astra J (Astra 4) with a 1.3 CDTI engine and Start-Stop system means there is a need to use more expensive batteries made with EFB technology. Dimensions of matching batteries differ slightly depending on the manufacturer and are 242x175x190 mm or 243x175x190 mm. The parameters of these batteries are at least 60 Ah of a capacity and 560 A CCA (Cold Cranking Amps). All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – diesel engines:
2.0 CDTI

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S4 S40 07	72 Ah 680 A	278x175x175 mm	More
Bosch S5 S50 07	74 Ah 750 A	278x175x175 mm	More
Exide Excell EB712	71 Ah 670 A	278x175x175 mm	More
Exide Premium EA722	72 Ah 720 A	278x175x175 mm	More
Lucas Premium LP100	72 Ah 680 A	278x175x175 mm	More
Lucas Supreme LS100	74 Ah 750 A	278x175x175 mm	More
Varta Blue Dynamic E43	72 Ah 680 A	278x175x175 mm	More
Varta Silver Dynamic E38	74 Ah 750 A	278x175x175 mm	More

The Opel Astra J (Astra 4) with a 2.0 CDTI diesel engine should be compatible with batteries of dimensions 276x175x175 mm or 278x175x175 mm, with a minimum capacity of 71 Ah. The most basic battery of this set is Exide Excell EB712 of a capacity 71Ah and 670A Cold Cranking Amps, the battery with the biggest capacity is Varta Silver Dynamic E38 of a capacity 74 Ah, having 750A Cold Cranking Amps. All batteries compatible with the 2.0 CDTI engine have a B13 mount.

Opel Astra J (Astra 4) – diesel engines:
1.7 CDTI – with Start-Stop

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S4 EFB S4 E08	70 Ah 650 A	278x175x190 mm	More
Exide EFB EL700	70 Ah 720 A	278x175x190 mm	More
Halfords Advanced EFB 096	75 Ah 700 A	278x175x190 mm	More
Lucas Fusion EFB LE096	70 Ah 650 A	278x175x190 mm	More
Varta Blue Dynamic EFB N70	70 Ah 760 A	278x175x190 mm	More
Varta Blue Dynamic EFB E45	70 Ah 650 A	278x175x190 mm	More

Owning a Opel Astra J (Astra 4) with a 1.7 CDTI engine and Start-Stop system means there is a need to use more expensive batteries made with EFB technology. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 650 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.

Opel Astra J (Astra 4) – diesel engines:
2.0 BiTurbo CDTI – with Start-Stop
2.0 CDTI – with Start-Stop

Model	Capacity and CCA	Dimensions (LxWxH)	Price
Bosch S5 AGM S5A 08	70 Ah 760 A	278x175x190 mm	More
Exide AGM EK700	70 Ah 760 A	278x175x190 mm	More
Exide AGM EK720	72 Ah 760 A	278x175x190 mm	More
Halfords Standard AGM 096	70 Ah 720 A	278x175x190 mm	More
Halfords Advanced AGM 096	70 Ah 760 A	278x175x190 mm	More
Lucas Fusion AGM LF096	70 Ah 760 A	278x175x190 mm	More
Varta Silver Dynamic AGM E39	70 Ah 760 A	278x175x190 mm	More

2.0 BiTurbo CDTI or 2.0 CDTI engines in the Opel Astra J (Astra 4) with Start-Stop system require the use of AGM technology batteries. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 720 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.

If you’re still unsure which battery fits your Opel Astra , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
