Opel Astra J (Astra 4) (2009-2015) – batteries


Choosing the right battery for the Opel Astra J (also known as Astra 4), manufactured between 2009 and 2015, is essential to ensure optimal performance and avoid starting issues, especially during colder months. Since this generation of the Astra was available in a variety of engine configurations, from small petrol units to powerful diesels, selecting a battery that matches your specific model is key. The type of start-stop system, engine displacement, and required cold cranking amps (CCA) all influence the ideal battery choice.

For petrol engines without the start-stop feature, such as the 1.4, 1.4 LPG, 1.6, and 1.6 Turbo variants, traditional lead-acid batteries are sufficient. These engines typically require batteries with a capacity between 60–62 Ah and a starting power in the range of 540–600 A. A critical consideration in these cases is the height of the battery: the battery compartment in these Astra models necessitates a reduced height of 175 mm, so standard-height batteries may not fit. Some of the example models that meet these criteria include Bosch S40 04, Exide EA612, and Varta D21, among others. These are widely available and reliable choices for daily driving needs.

For models equipped with the start-stop system, such as the 1.4 Turbo or 1.6 SIDI engines with that functionality, the requirements are more demanding. These vehicles benefit from advanced AGM (Absorbent Glass Mat) technology, which is better suited to frequent engine starts and stops. In these cases, batteries with a capacity of 70–72 Ah and higher CCA ratings (720–760 A) are recommended. Example AGM models include Bosch S5A 08, Exide EK700, and Varta E39. AGM batteries not only provide greater cycling capacity but also tend to last longer under urban driving conditions, where the start-stop system is more frequently engaged.

Diesel variants such as the 1.3 CDTI and 1.7 CDTI without start-stop systems follow a similar pattern to petrol engines, with 60–62 Ah batteries being sufficient. Again, due to limited space under the bonnet, make sure to opt for a battery no taller than 175 mm. For instance, models like Exide EB602 or Lucas LP075 are commonly recommended in such cases.

For diesel models with start-stop systems, such as the 1.3 CDTI, 1.7 CDTI, and 2.0 CDTI, either EFB (Enhanced Flooded Battery) or AGM batteries are used, depending on the model. The 1.3 CDTI with start-stop can use EFB batteries such as Bosch S4 E05 or Varta D53. The 2.0 CDTI BiTurbo and similar high-performance diesels with start-stop demand the robustness of AGM batteries, again in the 70–72 Ah capacity range.

A noteworthy fact is that start-stop systems significantly increase the number of battery cycles per day, which standard lead-acid batteries are not designed to handle. This is why EFB and AGM technologies were developed, providing greater charge acceptance and longevity. While AGM batteries are more expensive, they deliver enhanced reliability, especially for those who drive often in traffic or short distances.

One more tip for Opel Astra J owners: always double-check the terminal layout and battery dimensions before purchase. Some battery trays are designed for specific dimensions, and a mismatch may cause fitment issues. Additionally, newer batteries often come with improved cold-start performance even within the same Ah class, so it’s worth considering slightly higher CCA ratings if you live in colder climates.

In summary, the best battery for your Opel Astra J depends heavily on the engine version and presence of a start-stop system. Whether choosing a standard lead-acid battery or investing in AGM technology, selecting a model like the Bosch S40 04 or Varta E39—depending on your configuration—will help ensure smooth and reliable performance.

Opel Astra in version J (Astra 4) was produced in the years 2009 – 2015. We invite you to a list of batteries matching individual engine versions.

Basic parameters of batteries suitable for Opel Astra (2009-2015):

LayoutTerminal typesBase hold-down
0 – positive on the right side1B13

Opel Astra J (Astra 4) – petrol engines:
  • 1.4
  • 1.4 LPG
  • 1.4 Turbo
  • 1.6
  • 1.6 LPG
  • 1.6 SIDI
  • 1.6 Turbo (180 KM)

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 04
60 Ah
540 A
242x175x175 mmMore
Bosch S5
S50 04
61 Ah
600 A
242x175x175 mmMore
Exide Excell
EB602
60 Ah
540 A
242x175x175 mmMore
Exide Premium
EA612
61 Ah
600 A
242x175x175 mmMore
Halfords Standard
HCB 075
60 Ah
550 A
242x175x175 mmMore
Lucas Premium
LP075
60 Ah
540 A
243x175x175 mmMore
Lucas Supreme
LS075
62 Ah
600 A
242x175x175 mmMore
Varta Blue Dynamic
D59
60 Ah
540 A
242x175x175 mmMore
Varta Silver Dynamic
D21
61 Ah
600 A
242x175x175 mmMore
For the 1.4, 1.4 LPG, 1.4 Turbo petrol engines and others from the above list, we select batteries measuring 242x175x175 mm or 243x175x175 mm with a capacity exceeding 57 Ah. The weakest of these is the battery Bosch S4 S40 04 which capacity is 60 Ah and Cold Cranking Amps is 540 A. The most powerful battery is Lucas Supreme LS075 of a capacity 62Ah and Cold Cranking Amps: 600 A. All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – petrol engines:
  • 1.4 Turbo – with Start-Stop
  • 1.6 SIDI – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S5 AGM
S5A 08
70 Ah
760 A
278x175x190 mmMore
Exide AGM
EK700
70 Ah
760 A
278x175x190 mmMore
Exide AGM
EK720
72 Ah
760 A
278x175x190 mmMore
Halfords Standard
AGM 096
70 Ah
720 A
278x175x190 mmMore
Halfords Advanced
AGM 096
70 Ah
760 A
278x175x190 mmMore
Lucas Fusion AGM
LF096
70 Ah
760 A
278x175x190 mmMore
Varta Silver Dynamic AGM
E39
70 Ah
760 A
278x175x190 mmMore
1.4 Turbo or 1.6 SIDI engines in the Opel Astra J (Astra 4) with Start-Stop system require the use of AGM technology batteries. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 720 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.

Opel Astra J (Astra 4) – diesel engines:
  • 1.3 CDTI
  • 1.7 CDTI

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 04
60 Ah
540 A
242x175x175 mmMore
Bosch S5
S50 04
61 Ah
600 A
242x175x175 mmMore
Exide Excell
EB602
60 Ah
540 A
242x175x175 mmMore
Exide Premium
EA612
61 Ah
600 A
242x175x175 mmMore
Halfords Standard
HCB 075
60 Ah
550 A
242x175x175 mmMore
Lucas Premium
LP075
60 Ah
540 A
243x175x175 mmMore
Lucas Supreme
LS075
62 Ah
600 A
242x175x175 mmMore
Varta Blue Dynamic
D59
60 Ah
540 A
242x175x175 mmMore
Varta Silver Dynamic
D21
61 Ah
600 A
242x175x175 mmMore
For the Opel Astra J (Astra 4) with 1.3 CDTI or 1.7 CDTI diesel engines, we recommend batteries sized 242x175x175 mm or 243x175x175 mm, with a minimum capacity of 57 Ah. The most basic battery of this set is Bosch S4 S40 04 of a capacity 60Ah and 540A Cold Cranking Amps, the battery with the biggest capacity is Lucas Supreme LS075 of a capacity 62 Ah, having 600A Cold Cranking Amps. All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – diesel engines:
  • 1.3 CDTI – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4 EFB
S4 E05
60 Ah
560 A
242x175x190 mmMore
Exide EFB
EL600
60 Ah
640 A
242x175x190 mmMore
Halfords Advanced
EFB 027
65 Ah
600 A
243x175x190 mmMore
Lucas Fusion EFB
LE027
60 Ah
560 A
242x175x190 mmMore
Varta Blue Dynamic EFB
N60
60 Ah
640 A
242x175x190 mmMore
Varta Blue Dynamic EFB
D53
60 Ah
560 A
242x175x190 mmMore
Owning a Opel Astra J (Astra 4) with a 1.3 CDTI engine and Start-Stop system means there is a need to use more expensive batteries made with EFB technology. Dimensions of matching batteries differ slightly depending on the manufacturer and are 242x175x190 mm or 243x175x190 mm. The parameters of these batteries are at least 60 Ah of a capacity and 560 A CCA (Cold Cranking Amps). All the batteries in the list above have a base hold-down B13.

Opel Astra J (Astra 4) – diesel engines:
  • 2.0 CDTI

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 07
72 Ah
680 A
278x175x175 mmMore
Bosch S5
S50 07
74 Ah
750 A
278x175x175 mmMore
Exide Excell
EB712
71 Ah
670 A
278x175x175 mmMore
Exide Premium
EA722
72 Ah
720 A
278x175x175 mmMore
Lucas Premium
LP100
72 Ah
680 A
278x175x175 mmMore
Lucas Supreme
LS100
74 Ah
750 A
278x175x175 mmMore
Varta Blue Dynamic
E43
72 Ah
680 A
278x175x175 mmMore
Varta Silver Dynamic
E38
74 Ah
750 A
278x175x175 mmMore
The Opel Astra J (Astra 4) with a 2.0 CDTI diesel engine should be compatible with batteries of dimensions 276x175x175 mm or 278x175x175 mm, with a minimum capacity of 71 Ah. The most basic battery of this set is Exide Excell EB712 of a capacity 71Ah and 670A Cold Cranking Amps, the battery with the biggest capacity is Varta Silver Dynamic E38 of a capacity 74 Ah, having 750A Cold Cranking Amps. All batteries compatible with the 2.0 CDTI engine have a B13 mount.

Opel Astra J (Astra 4) – diesel engines:
  • 1.7 CDTI – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4 EFB
S4 E08
70 Ah
650 A
278x175x190 mmMore
Exide EFB
EL700
70 Ah
720 A
278x175x190 mmMore
Halfords Advanced
EFB 096
75 Ah
700 A
278x175x190 mmMore
Lucas Fusion EFB
LE096
70 Ah
650 A
278x175x190 mmMore
Varta Blue Dynamic EFB
N70
70 Ah
760 A
278x175x190 mmMore
Varta Blue Dynamic EFB
E45
70 Ah
650 A
278x175x190 mmMore
Owning a Opel Astra J (Astra 4) with a 1.7 CDTI engine and Start-Stop system means there is a need to use more expensive batteries made with EFB technology. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 650 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.

Opel Astra J (Astra 4) – diesel engines:
  • 2.0 BiTurbo CDTI – with Start-Stop
  • 2.0 CDTI – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S5 AGM
S5A 08
70 Ah
760 A
278x175x190 mmMore
Exide AGM
EK700
70 Ah
760 A
278x175x190 mmMore
Exide AGM
EK720
72 Ah
760 A
278x175x190 mmMore
Halfords Standard
AGM 096
70 Ah
720 A
278x175x190 mmMore
Halfords Advanced
AGM 096
70 Ah
760 A
278x175x190 mmMore
Lucas Fusion AGM
LF096
70 Ah
760 A
278x175x190 mmMore
Varta Silver Dynamic AGM
E39
70 Ah
760 A
278x175x190 mmMore
2.0 BiTurbo CDTI or 2.0 CDTI engines in the Opel Astra J (Astra 4) with Start-Stop system require the use of AGM technology batteries. Matching batteries have dimensions 278x175x190 mm. The parameters of these batteries are at least 70 Ah of a capacity and 720 A CCA (Cold Cranking Amps). The base hold-down of the above batteries is B13.
If you’re still unsure which battery fits your Opel Astra , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
