Choosing the correct battery for the Hyundai i30 CW II (GD) station wagon produced between 2012 and 2017 is crucial to ensuring the car’s electrical system performs reliably. This model was widely appreciated for its practicality, fuel efficiency, and solid build quality. Given the different petrol and diesel engine options, with and without Start-Stop systems, selecting a compatible battery requires close attention to technical specifications such as capacity, cold cranking amperage, and mounting type.
For petrol engines like the 1.4, 1.6, and 1.6 GDI, all of which lack Start-Stop technology, the battery capacity should be between 50 and 54 Ah, with a minimum starting power of 420 A and a maximum of 540 A. These are fairly standard requirements for small to mid-size petrol engines. These engines are well served by conventional lead-acid batteries. Some example models that are a good fit include Bosch S40 02, Exide EB500, Halfords HCB 012, Lucas LP079, and Varta C30. These batteries offer dependable starting performance and enough reserve capacity for common electrical needs like lighting, infotainment, and air conditioning.
For the diesel variants without Start-Stop, including the 1.4 CRDi and 1.6 CRDi, the requirements are slightly higher due to diesel engines needing more power to start, especially in colder climates. These engines require batteries in the 60–65 Ah range and cold cranking amperage between 390 and 580 A. However, one crucial aspect here is the mounting system. While many European cars use the standard B13 mount, these Hyundai diesel models often use B0 or Korean B1 mounting types. This means that not every 60 Ah battery will fit correctly, even if the technical specs match. Some examples of compatible batteries include Bosch S40 24, Exide EB604, Lucas LP005, and Varta D47. Ensuring the correct mounting type prevents unnecessary fitting issues during installation.
Diesel models equipped with Start-Stop systems, such as the 1.4 CRDi and 1.6 CRDi with this technology, require enhanced batteries due to the frequent engine restarts during urban driving. For these versions, EFB (Enhanced Flooded Battery) technology is necessary. These batteries are designed to handle the increased number of cycles and provide a stable energy supply even when the engine shuts off temporarily at stops. The required capacity for these engines ranges from 70 to 75 Ah, with a cold cranking power between 650 and 760 A. Some fitting EFB batteries include Bosch S4 E08, Exide EL700, Lucas LE096, Varta E45, and Halfords EFB 096. These are built to ensure long-term durability and reliable operation under demanding conditions.
One interesting detail about the Hyundai i30 CW II is that it blends Korean engineering with European styling and practicality. This model was designed with European roads and consumers in mind, which is reflected in the fact that certain variants diverge from Korean norms when it comes to battery sizes and terminal layouts. Still, certain aspects—like the less common mounting standards for diesel variants—show its Korean origin.
In conclusion, while the Hyundai i30 CW II offers a relatively simple battery selection process for petrol engines, diesel versions, especially those with Start-Stop, require closer inspection. Always verify not only the amp-hour rating and cranking power but also the correct mounting system and battery technology. Whether choosing a standard lead-acid or EFB type, using examples like those from Bosch, Varta, Exide, or Lucas ensures dependable performance and peace of mind on the road.
Hyundai i30 CW in version II (GD) station wagon was produced in the years 2012 – 2017. The following table presents information about batteries that match each of the engines available on the market.
Basic parameters of batteries suitable for Hyundai i30 CW (2012-2017):
| Layout | Terminal types | Base hold-down |
|---|---|---|
| 0 – positive on the right side | 1 | B13 |
| 0 – positive on the right side | 1 | Korean B1 |
| 0 – positive on the right side | 1 | B0 |
Hyundai i30 CW II (GD) station wagon – petrol engines:
- 1.4
- 1.6
- 1.6 GDI
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 02 | 52 Ah 470 A | 207x175x190 mm | More |
| Bosch S5 S50 02 | 54 Ah 530 A | 207x175x190 mm | More |
| Exide Excell EB500 | 50 Ah 450 A | 207x175x190 mm | More |
| Exide Premium EA530 | 53 Ah 540 A | 207x175x190 mm | More |
| Halfords Standard HCB 012 | 52 Ah 450 A | 207x175x190 mm | More |
| Lucas Premium LP079 | 50 Ah 420 A | 210x175x190 mm | More |
| Lucas Supreme LS012 | 58 Ah 520 A | 210x175x190 mm | More |
| Varta Blue Dynamic C22 | 52 Ah 470 A | 207x175x190 mm | More |
| Varta Silver Dynamic C30 | 54 Ah 530 A | 207x175x190 mm | More |
For the Hyundai i30 CW II (GD) station wagon produced from 2012 to 2017, equipped with petrol engines such as the 1.4 without Start-Stop, 1.6 without Start-Stop, and 1.6 GDI without Start-Stop, selecting the right battery is essential for reliable performance and long service life. These specific engine versions do not require Start-Stop technology, so they are compatible with standard lead-acid batteries designed for vehicles without enhanced energy recovery systems.
The recommended battery group for these engines features batteries with a length around 207–210 mm, a width of 175 mm, and a height of 190 mm, which ensures a proper fit in the battery compartment of the Hyundai i30 CW II. All suitable batteries have the polarity layout of 0 (positive terminal on the right when terminals are closest to you) and are equipped with standard terminal types (1) and B13 mounting, which matches the original specifications.
Popular and reliable options include the Bosch S4 S40 02 (52Ah, 470A), Bosch S5 S50 02 (54Ah, 530A), Varta Blue Dynamic C22 (52Ah, 470A), Varta Silver Dynamic C30 (54Ah, 530A), Exide Premium EA530 (53Ah, 540A), and Exide Excell EB500 (50Ah, 450A). Other compatible batteries from respected manufacturers are the Halfords Standard HCB 012 (52Ah, 450A), Lucas Supreme LS012 (58Ah, 520A), and Lucas Premium LP079 (50Ah, 420A). These batteries provide sufficient starting power and capacity for the typical electrical demands of the petrol variants without Start-Stop. When replacing the battery, always verify the dimensions, terminal layout, and mounting type to ensure a secure and correct installation.
Hyundai i30 CW II (GD) station wagon – diesel engines:
- 1.4 CRDi
- 1.6 CRDi
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 24 | 60 Ah 540 A | 232x173x225 mm | More |
| Exide Excell EB604 | 60 Ah 390 A | 230x173x222 mm | More |
| Exide Premium EA654 | 65 Ah 580 A | 230x173x222 mm | More |
| Lucas Premium LP005 | 60 Ah 540 A | 230x170x225 mm | More |
| Varta Blue Dynamic D47 | 60 Ah 540 A | 232x173x225 mm | More |
For the Hyundai i30 CW II (GD) station wagon with diesel engines—specifically the 1.4 CRDi without Start-Stop and the 1.6 CRDi without Start-Stop—there are several battery options that are compatible, reflecting the diversity of factory installations and minor design differences across model years. Unlike the petrol variants, these diesel engines generally require batteries with higher cold cranking amps (CCA) to provide reliable starting performance, especially in colder climates.
The most common battery size for these engines is the D23 case type, measuring approximately 230 mm in length, 173 mm in width, and around 222–225 mm in height. This ensures a secure fit within the battery tray and allows for easy installation. All presented batteries have the same polarity layout (0), meaning the positive terminal is on the right when the terminals are closest to you, and all use the standard European terminal type (1). However, you may notice small differences in mounting: some batteries come with a “Korean B1” hold-down (like Exide Premium EA654 and Exide Excell EB604), while others use the “B0” version (such as Bosch S4 S40 24, Varta Blue Dynamic D47, and Lucas Premium LP005). Both mounting types are suitable for this vehicle, but it’s important to check which style is currently installed in your car for the best fit.
There are also differences in battery capacity and starting power. For example, the Exide Premium EA654 offers a higher capacity (65Ah, 580A) compared to options like the Bosch S4 S40 24, Varta Blue Dynamic D47, or Lucas Premium LP005 (all around 60Ah, 540A). While both 60Ah and 65Ah batteries are suitable, choosing a battery with a higher amp-hour rating and cold cranking amps can provide extra assurance during winter or if the vehicle is frequently used for short trips. In all cases, it is highly recommended to compare the dimensions, hold-down/mounting type, and terminal layout of your current battery before purchasing a replacement, as even small differences can affect installation and stability.
Hyundai i30 CW II (GD) station wagon – diesel engines:
- 1.4 CRDi – with Start-Stop
- 1.6 CRDi – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 EFB S4 E08 | 70 Ah 650 A | 278x175x190 mm | More |
| Exide EFB EL700 | 70 Ah 720 A | 278x175x190 mm | More |
| Halfords Advanced EFB 096 | 75 Ah 700 A | 278x175x190 mm | More |
| Lucas Fusion EFB LE096 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB E45 | 70 Ah 650 A | 278x175x190 mm | More |
| Varta Blue Dynamic EFB N70 | 70 Ah 760 A | 278x175x190 mm | More |
For the Hyundai i30 CW II (GD) station wagon equipped with the 1.4 CRDi Start-Stop and 1.6 CRDi Start-Stop diesel engines, battery selection requires special consideration due to the inclusion of Start-Stop technology. These engines demand enhanced batteries that can withstand frequent cycling and provide reliable performance under higher electrical loads. As a result, EFB (Enhanced Flooded Battery) types are the recommended choice, as they are specifically designed for vehicles with Start-Stop systems and offer improved durability and charge acceptance compared to standard batteries.
The suitable batteries for these Start-Stop diesel variants all share the same essential characteristics in terms of size and mounting. They feature a length of 278 mm, a width of 175 mm, and a height of 190 mm, which ensures they fit securely into the battery tray of the Hyundai i30 CW II without any modifications. The polarity is 0—meaning the positive terminal is on the right when facing the terminals—while the terminal type is the standard European size (1). The mounting is B13, which matches the original equipment specification, ensuring proper stability and compatibility with the vehicle’s electrical system.
Leading options in this category include the Bosch S4 EFB S4 E08 (70Ah, 650A), Varta Blue Dynamic EFB E45 (70Ah, 650A), Exide EFB EL700 (70Ah, 720A), Varta Blue Dynamic EFB N70 (70Ah, 760A), Halfords Advanced EFB 096 (75Ah, 700A), and Lucas Fusion EFB LE096 (70Ah, 650A). These batteries all provide the necessary high cranking power and enhanced cycling resistance required for the Start-Stop function, supporting reliable engine starts and optimal operation of auxiliary systems. When upgrading or replacing the battery in your 1.4 CRDi or 1.6 CRDi Start-Stop model, always confirm the battery dimensions, polarity, mounting style, and EFB technology to maintain the vehicle’s Start-Stop capability and ensure long-lasting performance.
If you’re still unsure which battery fits your Hyundai i30 CW , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
