Fiat Grande Punto (2005-2012) – batteries



Fiat Grande Punto was produced in the years 2005 – 2012. Below we present the specifications of batteries suitable for specific engines.

Basic parameters of batteries suitable for Fiat Grande Punto (2005-2012):

LayoutTerminal typesBase hold-down
0 – positive on the right side1B13

Fiat Grande Punto – petrol engines:
  • 1.2 (69 KM)

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 00		44 Ah
420 A		175x175x190 mmMore
Exide Excell
EB440		44 Ah
400 A		175x175x190 mmMore
Varta Blue Dynamic
B36		44 Ah
420 A		175x175x190 mmMore
For the Fiat Grande Punto with a 1.2 (69 KM) gasoline engine, we choose batteries with dimensions of 175x175x190 mm, whose capacity exceeds 41 Ah. The weakest of these is the battery Exide Excell EB440 which capacity is 44 Ah and Cold Cranking Amps is 400 A. The most powerful battery is Varta Blue Dynamic B36 of a capacity 44Ah and Cold Cranking Amps: 420 A. All batteries compatible with the 1.2 (69 KM) engine have a B13 mount.

Fiat Grande Punto – petrol engines:
  • 1.2
  • 1.2 LPG
  • 1.4
  • 1.4 16V
  • 1.4 Abarth
  • 1.4 LPG
  • 1.4 Natural Power
  • 1.4 T-Jet

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 02		52 Ah
470 A		207x175x190 mmMore
Bosch S5
S50 02		54 Ah
530 A		207x175x190 mmMore
Exide Excell
EB500		50 Ah
450 A		207x175x190 mmMore
Exide Premium
EA530		53 Ah
540 A		207x175x190 mmMore
Halfords Standard
HCB 012		52 Ah
450 A		207x175x190 mmMore
Varta Blue Dynamic
C22		52 Ah
470 A		207x175x190 mmMore
Varta Silver Dynamic
C30		54 Ah
530 A		207x175x190 mmMore
For the 1.2, 1.2 LPG, 1.4 petrol engines and others from the above list, we select batteries measuring 207x175x190 mm with a capacity exceeding 47 Ah. The weakest of these is the battery Exide Excell EB500 which capacity is 50 Ah and Cold Cranking Amps is 450 A. The most powerful battery is Bosch S5 S50 02 of a capacity 54Ah and Cold Cranking Amps: 530 A. All of the above motors have a base hold-down B13.

Fiat Grande Punto – petrol engines:
  • 1.2 (69 KM) – with Start-Stop
  • 1.4 16V (105 KM) – with Start-Stop
  • 1.4 Abarth – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4 EFB
S4 E05		60 Ah
560 A		242x175x190 mmMore
Exide EFB
EL600		60 Ah
640 A		242x175x190 mmMore
Halfords Advanced
EFB 027		65 Ah
600 A		243x175x190 mmMore
Lucas Fusion EFB
LE027		60 Ah
560 A		242x175x190 mmMore
Varta Blue Dynamic EFB
D53		60 Ah
560 A		242x175x190 mmMore
The Fiat Grande Punto gasoline engines mentioned above are equipped with a Start-Stop system, and in this case, it means there is a need to use batteries produced using EFB technology. The dimensions of batteries suitable for 1.2 (69 KM), 1.4 16V (105 KM) and 1.4 Abarth engines vary slightly among different manufacturers and are: 242x175x190 mm or 243x175x190 mm. The parameters of these batteries are at least 60 Ah of a capacity and 560 A CCA (Cold Cranking Amps). All the batteries in the list above have a base hold-down B13.

Fiat Grande Punto – diesel engines:
  • 1.3 D Multijet
  • 1.3 D Multijet (85 KM)

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 02		52 Ah
470 A		207x175x190 mmMore
Bosch S5
S50 02		54 Ah
530 A		207x175x190 mmMore
Exide Excell
EB500		50 Ah
450 A		207x175x190 mmMore
Exide Premium
EA530		53 Ah
540 A		207x175x190 mmMore
Halfords Standard
HCB 012		52 Ah
450 A		207x175x190 mmMore
Varta Blue Dynamic
C22		52 Ah
470 A		207x175x190 mmMore
Varta Silver Dynamic
C30		54 Ah
530 A		207x175x190 mmMore
For the Fiat Grande Punto with 1.3 D Multijet or 1.3 D Multijet (85 KM) diesel engines, we recommend batteries sized 207x175x190 mm, with a minimum capacity of 47 Ah. The most basic battery of this set is Exide Excell EB500 of a capacity 50Ah and 450A Cold Cranking Amps, the battery with the biggest capacity is Bosch S5 S50 02 of a capacity 54 Ah, having 530A Cold Cranking Amps. All of the above motors have a base hold-down B13.

Fiat Grande Punto – diesel engines:
  • 1.3 D Multijet
  • 1.6 D Multijet
  • 1.9 D Multijet

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 05		60 Ah
540 A		242x175x190 mmMore
Bosch S5
S50 05		63 Ah
610 A		242x175x190 mmMore
Exide Excell
EB620		62 Ah
540 A		242x175x190 mmMore
Exide Premium
EA640		64 Ah
640 A		242x175x190 mmMore
Halfords Standard
HCB 027		62 Ah
550 A		242x175x190 mmMore
Lucas Supreme
LS027		65 Ah
640 A		242x175x190 mmMore
Varta Blue Dynamic
D24		60 Ah
540 A		242x175x190 mmMore
Varta Silver Dynamic
D15		63 Ah
610 A		242x175x190 mmMore
The three above-mentioned diesel engines, namely 1.3 D Multijet, 1.6 D Multijet and 1.9 D Multijet, should be paired with batteries sized 242x175x190 mm with a capacity of at least 59 Ah. The most basic battery of this set is Varta Blue Dynamic D24 of a capacity 60Ah and 540A Cold Cranking Amps, the battery with the biggest capacity is Lucas Supreme LS027 of a capacity 65 Ah, having 640A Cold Cranking Amps. All of the above motors have a base hold-down B13.

Fiat Grande Punto – diesel engines:
  • 1.3 D Multijet (85 KM) – with Start-Stop

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4 EFB
S4 E05		60 Ah
560 A		242x175x190 mmMore
Exide EFB
EL600		60 Ah
640 A		242x175x190 mmMore
Halfords Advanced
EFB 027		65 Ah
600 A		243x175x190 mmMore
Lucas Fusion EFB
LE027		60 Ah
560 A		242x175x190 mmMore
Varta Blue Dynamic EFB
D53		60 Ah
560 A		242x175x190 mmMore
Owning a Fiat Grande Punto with a 1.3 D Multijet (85 KM) engine and Start-Stop system means there is a need to use more expensive batteries made with EFB technology. Dimensions of matching batteries differ slightly depending on the manufacturer and are 242x175x190 mm or 243x175x190 mm. The parameters of these batteries are at least 60 Ah of a capacity and 560 A CCA (Cold Cranking Amps). All the batteries in the list above have a base hold-down B13.

Fiat Grande Punto – diesel engines:
  • 1.9 D Multijet

ModelCapacity and CCADimensions (LxWxH)Price
Bosch S4
S40 08		74 Ah
680 A		278x175x190 mmMore
Bosch S5
S50 08		77 Ah
780 A		278x175x190 mmMore
Exide Excell
EB740		74 Ah
680 A		278x175x190 mmMore
Exide Premium
EA770		77 Ah
760 A		278x175x190 mmMore
Halfords Standard
HCB 096		76 Ah
680 A		278x175x190 mmMore
Lucas Premium
LP096		75 Ah
680 A		278x175x190 mmMore
Lucas Supreme
LS096		78 Ah
780 A		278x175x190 mmMore
Varta Blue Dynamic
E11		74 Ah
680 A		278x175x190 mmMore
Varta Silver Dynamic
E44		77 Ah
780 A		278x175x190 mmMore
The Fiat Grande Punto with a 1.9 D Multijet diesel engine should be compatible with batteries of dimensions 276x175x190 mm or 278x175x190 mm, with a minimum capacity of 71 Ah. The most basic battery of this set is Varta Blue Dynamic E11 of a capacity 74Ah and 680A Cold Cranking Amps, the battery with the biggest capacity is Lucas Supreme LS096 of a capacity 78 Ah, having 780A Cold Cranking Amps. All batteries compatible with the 1.9 D Multijet engine have a B13 mount.
If you’re still unsure which battery fits your Fiat Grande Punto , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
