Choosing the right battery for your Citroen C4 Picasso I (2006-2013) is essential for maintaining your vehicle’s reliability and ensuring all electrical systems function as they should. The selection of a battery depends primarily on the engine type, whether the car is equipped with a Start-Stop system, and the specific power requirements of your model. Understanding these factors will help you make an informed decision and avoid common pitfalls associated with mismatched or inadequate batteries.
For C4 Picasso models with petrol engines such as the 1.6 16V, 1.6 VTi 120, 1.6 THP (140 and 155), 1.8 i 16V, and 2.0 i 16V, which do not feature Start-Stop technology, the recommended battery capacity typically ranges from 60 to 65 Ah, with a cold cranking amperage (CCA) between 540 and 640 A. These vehicles are compatible with traditional lead-acid batteries, which are both cost-effective and widely available. Among the suitable examples for these petrol engines are Bosch S40 05, Bosch S50 05, Exide EA640, Exide EB620, Halfords HCB 027, Lucas LP027, Lucas LS027, Varta D15, and Varta D24. These are just sample models; other brands and options meeting the required specifications can also be considered.
If you own a diesel-powered C4 Picasso like the 1.6 HDi or 1.6 HDi 110 without Start-Stop, the recommended specifications remain similar to those for petrol engines: a capacity of 60-65 Ah and a CCA of 540-640 A. These diesel models also use standard lead-acid batteries. Again, the aforementioned battery models are suitable examples, but it’s crucial to verify the fit and terminal layout before purchase. Diesel engines generally require higher starting power than their petrol counterparts, so always ensure the CCA meets or exceeds the specified range.
A notable exception within the C4 Picasso I range is the 1.6 HDi 110 engine equipped with the Start-Stop system. Vehicles with this technology require batteries capable of withstanding frequent charge and discharge cycles. For these models, an AGM (Absorbent Glass Mat) battery is necessary, with a capacity of 70-72 Ah and CCA between 720 and 760 A. Sample compatible AGM batteries include Bosch S5A 08, Exide EK700, Exide EK720, Halfords AGM 096, Lucas LF096, and Varta E39. AGM batteries are more advanced than traditional lead-acid types and are specially designed for Start-Stop vehicles. Their internal construction allows them to deliver high power and recover quickly, making them ideal for urban driving where the engine switches on and off frequently.
For the larger 2.0 HDi diesel engines (138, 150, and 165 HP) without Start-Stop, the requirements are higher still: battery capacity should fall between 74 and 78 Ah, with a CCA from 680 to 780 A. These models also use standard lead-acid batteries. Some suitable examples include Bosch S40 08, Bosch S50 08, Exide EA770, Exide EB740, Halfords HCB 096, Lucas LP096, Lucas LS096, Varta E11, and Varta E44. As always, these are just examples—it’s important to match the battery’s size, terminal positions, and specifications to your vehicle’s needs.
When selecting a battery, always check the physical dimensions and terminal orientation (polarity), as even batteries with the correct capacity may not fit the battery tray or connect properly. It’s also a good idea to consider the climate where you’ll be using your car. If you live in a particularly cold region, opting for a battery with a higher CCA rating can make cold starts more reliable. AGM batteries, aside from their advantages in Start-Stop systems, are also spill-proof and generally more resistant to vibration, which can be beneficial in various driving conditions.
Interestingly, the evolution of battery technology has paralleled advances in automotive electronics. Modern cars like the Citroen C4 Picasso I have increasingly complex electrical systems, requiring batteries that do more than just start the engine. From supporting infotainment and GPS to powering safety features, the battery plays a vital role even when the engine is off. This is especially true for models with Start-Stop, where the battery shoulders the added workload of restarting the engine repeatedly.
To sum up, when choosing a battery for your Citroen C4 Picasso I (2006-2013), always consult your owner’s manual for exact specifications, and consider reputable brands and models such as those listed above. Whether you need a conventional lead-acid or an advanced AGM battery, matching the technical requirements to your car’s configuration will ensure long-lasting, trouble-free operation. Remember that investing in a quality battery not only extends replacement intervals but also helps protect your vehicle’s sensitive electronics.
Citroen C4 Picasso in version I was produced in the years 2006 – 2013. Below we present the specifications of batteries suitable for specific engines.
Basic parameters of batteries suitable for Citroen C4 Picasso (2006-2013):
| Layout | Terminal types | Base hold-down |
|---|---|---|
| 0 – positive on the right side | 1 | B13 |
Citroen C4 Picasso I – petrol engines:
- 1.6 16V
- 1.6 THP 140
- 1.6 THP 155
- 1.6 VTi 120
- 1.8 i 16V
- 2.0 i 16V
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 05 | 60 Ah 540 A | 242x175x190 mm | More |
| Bosch S5 S50 05 | 63 Ah 610 A | 242x175x190 mm | More |
| Exide Excell EB620 | 62 Ah 540 A | 242x175x190 mm | More |
| Exide Premium EA640 | 64 Ah 640 A | 242x175x190 mm | More |
| Halfords Standard HCB 027 | 62 Ah 550 A | 242x175x190 mm | More |
| Lucas Premium LP027 | 60 Ah 540 A | 243x175x190 mm | More |
| Lucas Supreme LS027 | 65 Ah 640 A | 242x175x190 mm | More |
| Varta Blue Dynamic D24 | 60 Ah 540 A | 242x175x190 mm | More |
| Varta Silver Dynamic D15 | 63 Ah 610 A | 242x175x190 mm | More |
For the Citroen C4 Picasso I produced between 2006 and 2013 with petrol engines such as the 1.6 16V (without Start-Stop), 1.6 VTi 120 (without Start-Stop), 1.6 THP 140 (without Start-Stop), 1.6 THP 155 (without Start-Stop), 1.8 i 16V (without Start-Stop), and 2.0 i 16V (without Start-Stop), a specific group of batteries is recommended to ensure reliable starting and proper functioning of the vehicle’s electrical systems. These engines do not have Start-Stop technology, which means they require standard lead-acid batteries rather than specialized AGM or EFB types.
The most suitable batteries for these engines are those with a capacity generally ranging from 60Ah to 65Ah and a cold cranking amperage (CCA) between 540A and 640A. These specifications offer a balance between sufficient starting power and compatibility with the car’s battery bay dimensions. The batteries listed for these engines, such as the Bosch S4 S40 05 (60Ah, 540A), Bosch S5 S50 05 (63Ah, 610A), Varta Blue Dynamic D24 (60Ah, 540A), and Varta Silver Dynamic D15 (63Ah, 610A), all feature standard dimensions (approximately 242-243mm in length, 175mm in width, and 190mm in height), polarity layout 0 (positive terminal on the right), and B13 hold-down type, making them direct replacements for the original equipment.
Other recommended options include Exide Premium EA640 (64Ah, 640A), Exide Excell EB620 (62Ah, 540A), Halfords Standard HCB 027 (62Ah, 550A), Lucas Supreme LS027 (65Ah, 640A), and Lucas Premium LP027 (60Ah, 540A). All these batteries are standard lead-acid types, compatible with the mounting and electrical requirements of the specified Citroen C4 Picasso I petrol engines. Choosing any battery from this group will ensure proper fitment and optimal performance for everyday driving needs.
Citroen C4 Picasso I – diesel engines:
- 1.6 Hdi
- 1.6 HDi 110
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 05 | 60 Ah 540 A | 242x175x190 mm | More |
| Bosch S5 S50 05 | 63 Ah 610 A | 242x175x190 mm | More |
| Exide Excell EB620 | 62 Ah 540 A | 242x175x190 mm | More |
| Exide Premium EA640 | 64 Ah 640 A | 242x175x190 mm | More |
| Halfords Standard HCB 027 | 62 Ah 550 A | 242x175x190 mm | More |
| Lucas Premium LP027 | 60 Ah 540 A | 243x175x190 mm | More |
| Lucas Supreme LS027 | 65 Ah 640 A | 242x175x190 mm | More |
| Varta Blue Dynamic D24 | 60 Ah 540 A | 242x175x190 mm | More |
| Varta Silver Dynamic D15 | 63 Ah 610 A | 242x175x190 mm | More |
For the Citroen C4 Picasso I equipped with the 1.6 HDi and 1.6 HDi 110 diesel engines without Start-Stop technology, the range of suitable batteries closely matches those recommended for the petrol variants in terms of size and technical specifications. Since these diesel engines also do not utilize Start-Stop systems, there is no need for AGM or EFB battery types, and a standard lead-acid battery is fully sufficient to provide reliable cold starting performance and consistent operation of the vehicle’s electrical systems.
The recommended batteries for these diesel engines have capacities typically between 60Ah and 65Ah, with cold cranking amperage (CCA) ratings from 540A up to 640A. Diesel engines, especially in colder climates, benefit from higher CCA values to ensure smooth starting, and all batteries listed—such as the Bosch S4 S40 05 (60Ah, 540A), Bosch S5 S50 05 (63Ah, 610A), Varta Blue Dynamic D24 (60Ah, 540A), Varta Silver Dynamic D15 (63Ah, 610A), Exide Premium EA640 (64Ah, 640A), and others—fulfill these requirements. Their dimensions (about 242-243mm long, 175mm wide, and 190mm high) and terminal layout (polarity 0, with the positive terminal on the right) match the original Citroen specifications, and the B13 base ensures straightforward installation in the battery tray.
Choosing from this group—including trusted brands like Bosch, Varta, Exide, Halfords, and Lucas—will provide your Citroen C4 Picasso I 1.6 HDi or 1.6 HDi 110 with the necessary power and reliability for daily use. These batteries are designed for standard mounting and feature universal terminal types, so you can be confident of compatibility with your vehicle’s electrical system and mounting hardware. For owners seeking peace of mind and dependable starts in all conditions, any of the batteries within these specifications will be an excellent choice for the diesel-powered C4 Picasso I without Start-Stop.
Citroen C4 Picasso I – diesel engines:
- 2.0 HDi 138
- 2.0 HDi 150
- 2.0 HDi 165
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S4 S40 08 | 74 Ah 680 A | 278x175x190 mm | More |
| Bosch S5 S50 08 | 77 Ah 780 A | 278x175x190 mm | More |
| Exide Excell EB740 | 74 Ah 680 A | 278x175x190 mm | More |
| Exide Premium EA770 | 77 Ah 760 A | 278x175x190 mm | More |
| Halfords Standard HCB 096 | 76 Ah 680 A | 278x175x190 mm | More |
| Lucas Premium LP096 | 75 Ah 680 A | 278x175x190 mm | More |
| Lucas Supreme LS096 | 78 Ah 780 A | 278x175x190 mm | More |
| Varta Blue Dynamic E11 | 74 Ah 680 A | 278x175x190 mm | More |
| Varta Silver Dynamic E44 | 77 Ah 780 A | 278x175x190 mm | More |
For Citroen C4 Picasso I models equipped with the 2.0 HDi 138, 2.0 HDi 150, and 2.0 HDi 165 diesel engines without Start-Stop technology, a higher-capacity battery is recommended to meet the increased energy demands of these larger, more powerful engines. Unlike the smaller diesel and petrol variants, these 2.0 HDi engines require batteries with greater amp-hour capacity and higher cold cranking amperage (CCA) to ensure reliable starting, especially in colder temperatures where diesel engines typically need more power to turn over.
The most suitable batteries for these engines are standard lead-acid types with a capacity ranging from 74Ah to 78Ah and a CCA between 680A and 780A. Leading options include the Bosch S4 S40 08 (74Ah, 680A), Bosch S5 S50 08 (77Ah, 780A), Varta Blue Dynamic E11 (74Ah, 680A), and Varta Silver Dynamic E44 (77Ah, 780A), all of which fit precisely in the vehicle’s battery compartment thanks to their standard dimensions of 278mm in length, 175mm in width, and 190mm in height. These batteries feature polarity layout 0 (positive terminal on the right) and the B13 hold-down configuration, matching the original Citroen specifications for secure mounting and correct electrical connection.
Other trusted brands, such as Exide, Halfords, and Lucas, also offer compatible batteries for these engines: Exide Premium EA770 (77Ah, 760A), Exide Excell EB740 (74Ah, 680A), Halfords Standard HCB 096 (76Ah, 680A), Lucas Supreme LS096 (78Ah, 780A), and Lucas Premium LP096 (75Ah, 680A). All options listed are designed for standard mounting and utilize universal terminal types, ensuring direct replacement for the factory-fitted battery. By selecting one of these high-capacity batteries, owners of the 2.0 HDi C4 Picasso I can be assured of dependable starting performance, robust support for onboard electronics, and long-lasting durability—key factors for both everyday driving and more demanding conditions.
Citroen C4 Picasso I – diesel engines:
- 1.6 HDi 110 – with Start-Stop
| Model | Capacity and CCA | Dimensions (LxWxH) | Price |
|---|---|---|---|
| Bosch S5 AGM S5A 08 | 70 Ah 760 A | 278x175x190 mm | More |
| Exide AGM EK700 | 70 Ah 760 A | 278x175x190 mm | More |
| Exide AGM EK720 | 72 Ah 760 A | 278x175x190 mm | More |
| Halfords Standard AGM 096 | 70 Ah 720 A | 278x175x190 mm | More |
| Halfords Advanced AGM 096 | 70 Ah 760 A | 278x175x190 mm | More |
| Lucas Fusion AGM LF096 | 70 Ah 760 A | 278x175x190 mm | More |
| Varta Silver Dynamic AGM E39 | 70 Ah 760 A | 278x175x190 mm | More |
For the Citroen C4 Picasso I fitted with the 1.6 HDi 110 engine equipped with Start-Stop technology, the requirements for a suitable replacement battery are notably different from those for standard diesel or petrol variants. The Start-Stop system places increased demands on the battery, as it is responsible not only for starting the engine but also for supporting frequent cycles of engine shutdown and restart, as well as powering onboard electrical systems when the engine is off. Because of this, only AGM (Absorbent Glass Mat) batteries are recommended for these models, as they are specifically engineered to handle deep cycling, rapid charging, and the high energy throughput associated with Start-Stop operation.
The ideal batteries for the 1.6 HDi 110 Start-Stop engine are all AGM types with a capacity of 70Ah to 72Ah and a high cold cranking amperage (CCA), typically around 760A. These batteries include the Bosch S5 AGM S5A 08 (70Ah, 760A), Varta Silver Dynamic AGM E39 (70Ah, 760A), Exide AGM EK700 (70Ah, 760A), Exide AGM EK720 (72Ah, 760A), Halfords Advanced AGM 096 (70Ah, 760A), Halfords Standard AGM 096 (70Ah, 720A), and Lucas Fusion AGM LF096 (70Ah, 760A). All of these batteries share standard dimensions of 278mm in length, 175mm in width, and 190mm in height, with terminal layout 0 (positive on the right) and B13 mounting, ensuring precise fit and secure installation in the original battery tray.
These AGM batteries are designed to deliver sustained high performance and reliability under the intensive operating conditions imposed by the Start-Stop system. Their advanced internal construction allows them to maintain voltage stability even during repeated engine starts and periods of high accessory use. Using an AGM battery from the list above will guarantee full compatibility with the electronic management systems of the 1.6 HDi 110 Start-Stop engine, helping to preserve both the battery’s service life and the correct functioning of all vehicle systems. Selecting a battery from a reputable manufacturer such as Bosch, Varta, Exide, Halfords, or Lucas will ensure dependable starting, efficient energy management, and optimal performance for your Citroen C4 Picasso I with Start-Stop technology.
If you’re still unsure which battery fits your Citroen C4 Picasso , or if you want to help others in their selection, please send us a photo of your current battery in the comment section at the bottom of the page. You can also send the picture to contact@whatbattery.co.uk (we will place it in the comments to also help other users). Be sure to specify the car model, year, type, as well as the engine capacity and power. We’ll do our best to assist you!
